- Place of Origin: Changsha
- Brand Name: SANY
- Model Number: SYL956H
Optimum Efficiency
Cummins QSL8.9 Engine: ensures strong power, high efficiency and large displacement.
Multipoint fuel injection allows for immediate throttle response, enhanced fuel efficiency and reduced noise.
Meets Tier 3 emission standard.
Customized DANA Transmission: The DANA axis-shift transmission with electronic control system is used for automatic shifting, maximum efficiency and 10k-hour service life.
F/R handle and fingertips control realize ease of switch between left and right hands.
Solenoid valve logic control achieve a much smoother shifting and faster response.
High-Pressure Load-Sensitive Hydraulic System: perfect match between speed and power, 10%-15% energy saving.
The 25MPa high-pressure hydraulic system and main valve of large displacement achieve higher breakout and lifting force.
Superior Reliability
Braking System: The full hydraulic electronic control parking brake and dual circuit service brake combine maneuverability and reliability, ensuring a safe operating experience.
Reinforced structural components are adopted for heavy-duty mining applications with a service life reaching 10k hours.
High Fuel Efficiency
The Cummins QSL8.9 engine reduces the fuel consumption of the wheel loader.
The high-pressure load-sensitive hydraulic system and leading hydraulic components distribute the flow on demand, reducing the unnecessary energy loss and saving energy by up to 10%.
Comfortable Operating Experience
Spacious & Quiet Cab
Generous legroom and visibility, 15% larger than other Chinese wheel loaders.
Reduced noise with 78 dB(A) noise level, creating a super comfortable space for the operators.
Ergonomic Design
Large and soft wrist rest with the height easy to adjust.
Enough legroom, comfortable pedal design, and the angle adjustable steering.
Exclusive Advisor Mr.Raymond
E-mail: sanyraymond@163.com
wechat: zirurocky
whatsapp: 86 186 6378 8576
- Place of Origin: Changsha
- Brand Name: SANY
- Model Number: SYL956H
Basic | Operabng Weight | kg | 17100±200 |
Bucket Capacity (Std.) | m3 | 2.7-40 | |
Max Torque | N m | 1000 | |
Rated Load | kg | 5000 | |
Engine | Model | Cummins QSL8 9-C220-HI | |
Rated power | kW/rpm | 164/2200 | |
Emission Standard | Tier 3 | ||
Pefformance | Speed (Gearl) | Km/h | 7.1 |
Max Speed | Km/h | 40 | |
Total Hydraulic Cycle Time | s | 10.5 | |
Max SAE | kN | 175 | |
Tractive Force | kN | 167 | |
Max Articulation Angle | . | 40 | |
Dumping Height at 45, Discharge | mm | 3118 | |
Dumping Reach at 45* Discharge | mm | 1140 | |
Tipping Load. Articulated at 40* | kg | 10700 | |
Tipptng Load, Straight | kg | 12600 | |
Service Refill Capacities | Fuel Tank | L | 300 |
Hyd Tank | L | 220 | |
Drive Axle Oil (Front/Rear) | L | 262/262 | |
Engine Coolant | L | 45 | |
Dimensions | A. Max Lifting Height | mm | 5410150 |
B Max Height of Bucket Pivot Point | mm | 4132±50 | |
C Dumping Height | mm | 3118150 | |
D Transport Height | mm | 460 | |
E Digging Depth | mm | 30 | |
F Dumping Reach | mm | 1140 ±50 | |
H Machine Height | mm | 3501 ±50 | |
K Ground Clearance | mm | 432 ± 10 | |
L Machine Length (wrth Bucket) | mm | 8016150 | |
M Articulation Cenw to Rear Wheel Cent,, | mm | 1600 | |
N Wheelbase | mm | 3200 | |
P Rear Overhang | mm | 2229150 | |
Q Counteiweight to Bucket Pivot Point | mm | 6807150 | |
W Machine Width | mm | 2825±50 | |
X Track Width | mm | 2200 | |
Y Bucket Width | mm | 3000 | |
R1. Turning Radius (Bucket) | mm | 6450150 | |
R2 Min Turning Radius (Wheel) | mm | 5850 ±50 |
